High-Temperature Furnace with SiC Heating Rods LHS 08/15 up to 1500 °C
Max temp: 1500°C | Volume: 8,4 l | Voltage: 400 V
Laboratory furnace with silit rod heating for high-temperature processes up to 1500 °C
Looking for a furnace for demanding laboratory processes at very high temperatures?
The LHS 08/15 model is a desktop laboratory furnace with silit rods designed for controlled heat treatment up to 1500 °C.
- You need high-temperature operation up to 1500 °C
- You require rapid achievement of the required temperature
- You want compact dimensions without a bulky transformer
- You are looking for a furnace suitable for sintering, testing of materials or similar laboratory applications
Key features:
- Maximum temperature 1500 °C
- Maximum temperature for long-term use 1450 °C
- Inner volume 8.4 l
- Silit rods on the furnace sides
- Thermocouple Type “B”
- Forced jacket cooling with ventilator fan
- Contactless switching relay for noiseless operation
Typical applications
This laboratory furnace is suitable for high-temperature laboratory processes, especially where standard resistance wire furnaces can no longer operate. It is suitable for applications requiring rapid temperature increase and reliable high-temperature operation.
- Sintering – solid state, liquid phase and powder sintering
- Testing of materials
- Enamel firing (partially suitable)
- Melting of metal materials (partially suitable)
- Fusing of glass (partially suitable)
Available models in this series
- LHS 03/14 (product detail) – approx. 3 l chamber volume up to 1400 °C
- LHS 08/14 (product detail) – approx. 8.4 l chamber volume up to 1400 °C
- LHS 15/14 (product detail) – approx. 14.4 l chamber volume up to 1400 °C
- LHS 03/15 (product detail) – approx. 3 l chamber volume up to 1500 °C
- LHS 08/15 – approx. 8.4 l chamber volume (this model)
- LHS 15/15 (product detail) – approx. 14.4 l chamber volume up to 1500 °C
Ideal choice if
- You need a laboratory furnace up to 1500 °C
- You require rapid heat-up to the required temperature
- You work with medium sample volumes
Main benefits
- Rapid achievement of the required temperature
- Heating elements with long service life
- Temperature shock-resistant silit rod heating elements
- Convenient furnace servicing
For lower-temperature laboratory applications, consider the LH, L or LE series according to the required temperature range.
Optional features
- Controller Ht205 (30 programs with 15 steps each)
- Protective atmosphere inlet (manually or automatically controlled gas supply)
- Ejector with exhaust fan and draft diverter for the extraction of fumes
- Protective bottom plate
- Calibration of controller input measurement
- Interface RS232, EIA485 or Ethernet including cable and software
- HtMonit set (software + interface)
Contact us or use our sample testing services.
For technical specifications, construction and design, please refer to the product page.
| Category: | Laboratory furnaces |
|---|---|
| Warranty: | 3 years |
| Weight: | 60 kg |
| Tmax °C: | 1500 |
| Recommended operating temperature range in °C: | 700 - 1500 |
| Volume in l: | 8,4 |
| External dimensions (w × h × d) mm: | 490×615×680 |
| Internal dimensions (w × h × d) mm: | 170×170×290 |
| Input in kW: | 8 |
| Weight in kg: | 60 |
| Voltage V: | 400 |
| Max. load capacity of bottom in kg: | 5 |
You need a high-temperature laboratory furnace for demanding processes up to 1400 / 1500 °C with fast heating and stable performance.
The LHS series uses SiC-based heating rods, enabling rapid heat-up, high temperature capability and reliable operation in demanding thermal processes where standard resistance heating is no longer sufficient.
Suitable for applications with elevated temperature requirements or intensive thermal cycles. For standard laboratory processes, consider conventional muffle furnaces such as the L or LH series.
Explore LHS models designed for high-temperature applications ↓
